saltstack-wrt: Install and configure a router minion

This project provides Salt 3008.3 minion packages for OpenWrt and Turris OS. The packages use TCP transport and include optional router modules. The Salt master runs on a separate computer.

Salt documentation

Topic	Official Salt 3008 documentation
Configure a minion	Minion configuration
Configure a master	Master configuration
Use TCP transport	TCP transport
Write and apply states	Salt states tutorial

1. Select packages for the router

Use the output for your target system:

Target	System	Architecture	Package output
Turris Omnia	Turris OS 9.1.1	arm_cortex-a9_vfpv3-d16	openwrt/output/omnia/
OpenWrt x86_64	OpenWrt 24.10.8	x86_64	openwrt/output/x86_64/

When you use the test repository's build wrappers, these paths are in that repository. When you build the package repository directly, they are in the package repository.

Check the router before you select IPK files:

cat /etc/os-release
opkg print-architecture
df -h /overlay /tmp

Package	Purpose
python3-salt	Shared Python runtime. Required.
salt-minion	Minion commands, configuration, and init script. Required.
minion-opkg	Package management through pkg.*. Optional.
minion-uci	UCI functions, UCI states, and wrt_config. Optional.
minion-service	Service management through procd and ubus. Optional.
minion-openwrt	Metapackage that requires all router add-ons. Optional.

The complete profile includes all six packages. For a minimal installation, use the two required packages and the needed dependencies. Add only the modules you need; omit minion-openwrt if you omit an add-on. The add-ons must match the base Salt package release.

For the complete profile, use install-local.txt from the target output directory. It lists the local IPK files, including any local Python compatibility packages. Copy every listed IPK and the manifest to /tmp/salt-ipk/ on the router. Use the exact filenames in the manifest.

Do not install every exported IPK with opkg install *.ipk. The export also includes system dependencies for build and test use. The router's configured feeds should supply existing system dependencies. install-all.txt lists the full dependency export; it is not the router installation list.

2. Configure the minion before installation

On the router, create the configuration directory:

mkdir -p /etc/salt/minion.d

Create /etc/salt/minion.d/local.conf:

master: 192.168.1.10
id: openwrt-test
transport: tcp
master_port: 4506

Use your master's address and a unique minion ID. Keep transport: tcp; the package does not include ZeroMQ support. This file overrides the shipped minion defaults through Salt's minion.d/*.conf include.

The example uses a TCP master on its standard request port, 4506. For a dedicated TCP master, set transport: tcp in /etc/salt/master.d/tcp.conf and restart the master. The minion must also reach the master's TCP publication port, normally 4505.

The shipped router configuration uses port 4606 for the test repository's mixed-transport master. For that master or the playground, use master_port: 4606 instead. Its TCP publication port is 4605. Match the port to your master's actual configuration.

minion-service installs its provider selection in /etc/salt/minion.d/20-openwrt-service.conf. You do not need an additional provider file for opkg, UCI, or wrt_config.

3. Install and start the minion

For an upgrade, stop the existing minion locally before installation. Upgrade the base packages and all installed add-ons together. Do not use force options to bypass dependency checks.

For the complete profile, install the local files in one opkg call. On the router, execute:

cd /tmp/salt-ipk
opkg update

Continue only if the feed update succeeds. Load the filenames from the manifest and install them:

set --
while IFS= read -r ipk; do
    [ -z "$ipk" ] || set -- "$@" "$ipk"
done < install-local.txt
[ "$#" -gt 0 ] && opkg install "$@"

Continue only if installation succeeds.

OpenWrt starts and enables the minion during a fresh installation. Turris uses its system service policy and can leave an unlisted service disabled. After installation, execute locally:

salt-call --local test.ping
/etc/init.d/salt-minion enable
/etc/init.d/salt-minion restart
/etc/init.d/salt-minion status

Restart after configuration or add-on changes so that the running minion loads them.

4. Accept the key and test the connection

On the router, read the minion key fingerprint:

salt-call --local key.finger

On the master, inspect the key for the same minion ID:

salt-key -f openwrt-test

Compare the fingerprints. Accept the key only if they match:

salt-key -a openwrt-test
salt openwrt-test test.ping

A successful ping returns True. For connection problems, inspect logread and /var/log/salt/minion on the router.

Router module guides

Module	Use it to	Guide
pkg	Install missing packages and remove installed packages.	opkg
uci	Read configuration and use a separate commit step.	UCI
wrt_config	Manage and save one UCI configuration in one state.	wrt_config
service	Manage procd services and apply saved configuration.	service/procd
